Turing MA640H Uncooled Infrared Module

China Moneypro

Turing MA640H uncooled infrared module provides multiple serialized lenses and various kinds of user extension components, offering trustworthy solutions to high-reliability application scenarios. It is widely applied to fields of outdoor observation, integrated pods and driving assistance.

Get in Touch

Feature

High Reliability

Impact resistance reaching 1000g@0.3ms.

Excellent Performance

Support shutterless algorithms, providing a smooth and continuous user experience.

Multiple Selections

Provide 10+ a thermalized lenses applicable to apps with different imaging distances.
Provide multiple interface options such as USB, DVP, BT656, LVCMOS, and analog video.

Specification

Performance Indicators
Detector Type	Uncooled VOx infrared detector
Resolution	640×512
Frame Rate	50 Hz (60 Hz, optional)
Pixel Pitch	12μm
Spectral Band	8~14μm
NETD	≤40mK at 25℃, F#1.0
Image Adjustment
Polarity	Black-hot/White-hot
Palette	Support
Reticle	Display/Blank/Move
Digital Zoom	1.0~8.0 continuous zoom (step size:0.1)
Image Processing	Scene-based non-uniformity correction, digital filtering noise reduction, and digital detail enhancement, Shutterless
Mirroring	Horizontal/Vertical/Diagonal
Power Supply
Power Supply Range (typical)	3.9~5V DC, 5~18V DC supported by user extension components
Typical Power Consumption at 25°C Without Extension	≤0.7W
Power Protection	Overvoltage, undervoltage, and reverse connection supported by user extension components
Interface
Digital Video	BT.656/DVP/LVCMOS
Analog Video	1-channel PAL system
Serial Communication Interface	RS232/UART (3.3V)
Extension Components	MIPI/USB/Analog video/BT.656/DVP
Physical Characteristics
Dimensions (Without lens and extension components)	26mm×26mm×19.8mm
Weight (3.2mm, without extension components)	21g±1g
Environment Adaptability
Operating Temperature	-40°C~+80°C
Storage Temperature	-45℃～+85℃
Humidity	5 ~ 95%, non-condensing
Vibration	6.06g, random vibration, all axes
Impact	1000g@0.3ms, optical axis direction
