S070DA Two-Axis Dual-Light Pod

I. Product Introduction

The MS070DA miniature optoelectronic pod consists of an uncooled infrared thermal imager, a visible light camera, a two-axis servo-stabilized platform, and an image processing component (autonomous recognition and tracking). It features ultra-small size, ultra-light weight, high precision, and low latency, and can be applied to small and micro UAVs to perform day and night reconnaissance and surveillance missions over target areas.

The optoelectronic pod uses an uncooled infrared thermal imager and a visible light camera to detect, identify, and track ground targets around the clock, while simultaneously outputting infrared and visible light video in real time for mission personnel to view.

This miniature pod has been adapted to several mainstream flight control platforms in China, enabling seamless integration with flight control systems; it can also be connected to our ViewControlStudio display and control software platform to assist the overall unit in quickly completing the development of the UAV system.

This optoelectronic pod is mainly used in scenarios such as reconnaissance, guidance, border patrol, personnel search and rescue, and forest fire prevention.

I. Photos of the actual product

Figure 1 Product Image

II. Product Functions

a) It has self-testing and fault reporting functions;

b) It has the ability to detect long-wave infrared and visible light bands and can output infrared and visible light images;

c) Possesses the ability to move freely along two axes: azimuth and pitch;

d) Possesses the ability to receive commands from the control station and complete pod operations;

e) Possesses the ability to isolate carrier disturbances and stabilize the line of sight;

f) It has the function of locking/unlocking targets, and after locking the target, the pod outputs an image with a tracking frame;

g) It has an automatic target tracking function, can automatically track targets, and has the ability to resist natural interference;

h) It has a memory tracking function, which allows the target to be recaptured in a short time after being briefly lost;

i) It has the function of adjusting the gate size;

j) It has the function of switching tracking points;

k) It can communicate bidirectionally with the control station via RS422/100Mbps network and output information such as infrared images, visible light images, system working status, camera working status, and optical axis position;

l) Equipped with photo and video recording functions;

m) Possesses typical target (person, vehicle) detection capabilities;

III. Mounting Platform

Miniature rotary-wing drones, fixed-wing drones, loitering munitions, etc.

IV. Main Technical Parameters

model	S070DA
Infrared thermal imager
Detector type	Uncooled focal plane detector
Operating band	8μm～14μm
Detector resolution	640×512
Pixel size	12μm
Lens focal length	25mm
Field of view	17.5°×13.1°
Visible light camera
resolution	2560×1440
focal length	16mm
Field of view	26.1° x 14.9°
Video resolution	1920×1080
Servo Platform
Orientation angle	-90° to +90°
Pitch angle	-90° to +30° (positive for upward)
Angular position accuracy	≤0.3°
Stable accuracy	≤0.1mrad (1σ1°/2Hz, 2°1Hz)
Maximum angular velocity	Azimuth ≥ 50°/s, Pitch ≥ 50°/s
Image processing components
Automatic recognition	Capable of automatically recognizing people and vehicles with a target count of ≥32.
Automatic tracking	Target size ≥ 16×16
Tracking frame rate	50Hz
Image output	RTSP/UDP/RTMP are selectable, and the bitrate can be set from 100kbps to 6Mbps.
System Indicators
Image tracking	Automatically track selected target
Power supply voltage	14V to 28VDC
power	Stable power consumption: ≤12W Peak power consumption: ≤20W
weight	≤250g
volume	≤70mm×73mm×93mm
interface
Control Interface	RS422
Video interface	100M network
Storage interface	≥32GB memory card (Mini SD card)
External plug-ins	J30-15ZKP
Image format	JPG format
Video format	AVI format
Environmental adaptability
Operating temperature	-40℃～＋55℃
Storage temperature	-40℃ to +60℃
Shock resistance	≥400g
