China Moneypro MMY528B Fusion Binocular with Infrared and Low-Lux CMOS
China Moneypro
China Moneypro MMY528B Fusion Binocular is designed for individual handheld day/night battlefield observation, featuring camouflage detection capability and superior performance in diverse environments. This advanced binocular integrates multiple imaging modes for unmatched adaptability, including Low Light, IR Image, Black & White Fusion, and Color Fusion.
With cutting-edge infrared technology and low-lux CMOS sensor, it ensures precise observation and detection under challenging conditions such as darkness, low light, and camouflage. The dual-screen display and intelligent regulation system deliver enhanced clarity and operational efficiency for both professional and tactical applications.
With cutting-edge infrared technology and low-lux CMOS sensor, it ensures precise observation and detection under challenging conditions such as darkness, low light, and camouflage. The dual-screen display and intelligent regulation system deliver enhanced clarity and operational efficiency for both professional and tactical applications.
Key Features
- Supports four operation modes: Low light, IR image, Black & White Fusion, and Color Fusion.
- High-definition displaywith large format imaging, supporting image and video recording playback, delete functions, and automatic backup for unexpected power failure.
- Battery voltage indicatorand reverse battery protection for extended safety.
- Adjustable focus, contrast, brightness, and quick polarity switch between white hot and black hot modes.
- Video & data communication portensures high-quality and sensitivity images on OLED display or external monitor.
Technical Parameters
Thermal Camera
- Detector Type: Uncooled FPA
- Resolution: 800 × 600
- Wavelength: 17μm
- FOV: 16° × 12°
Low-Light Camera
- Resolution: 800 × 600
- Wavelength: 18μm
- FOV: 16° × 12°
Power
- Battery: 4 × 18650 rechargeable batteries
- Consumption: ≤5.5W
- Operation Time: ≥6 hours (ambient temperature)
Built-in Storage
- Stores ≥10,000 still images & ≥2 hours of video
Physical Characteristics
- Weight: ≤1.2kg (including binocular, batteries, eye-cups, lens cap, wristband)
Environmental Adaptability
- Operating Temperature: -40°C ~ +55°C
- Storage Temperature: -55°C ~ +70°C
Accessories
- Backup Batteries
- Charger
- Safety Case
- USB Cable
- Adapter
- Tripod
- Carrying Bag (optional)
Effective Range
Low-Light Mode
- Recognition: Personnel 0.2km | Vehicle 0.45km
- Detection: Personnel 0.35km | Vehicle 0.7km
Infrared Mode (IR)
- Recognition: Personnel 0.45km | Vehicle 0.9km
- Detection: Personnel 0.9km | Vehicle 1.8km
5 Professional FAQ
Q1: What makes China Moneypro MY528B unique compared to conventional night vision binoculars?
A1: Unlike standard night vision, China Moneypro MY528B integrates infrared and low-lux CMOS fusion, enabling camouflage detection and superior recognition in complex environments.
Q2: How long can the device operate continuously on a full charge?
A2: With 4 × 18650 rechargeable batteries, it offers over 6 hours of continuous operation under ambient conditions.
Q3: What storage capacity is available for images and videos?
A3: China Moneypro MY528B has built-in storage for up to 10,000 still images and 2 hours of video recording.
Q4: How effective is the camouflage detection feature in practical use?
A4: The fusion of multi-spectral imaging modes (IR + low-light) significantly improves detection of hidden personnel and vehicles, especially in woodland and urban terrains.
Q5: What environmental conditions can China Moneypro MY528B withstand?
A5: It is designed for extreme adaptability, with operating temperatures from -40°C to +55°C and storage temperatures from -55°C to +70°C, ensuring reliability in diverse climates.
