MAT31 Motorized Focusing Thermal Camera
China Moneypro
MAT31 is a high-performance and high-precision electrically adjustable temperature measurement thermal imager that uses a uncooled focal plane detector and offers multiple lens options.
Supporting multiple protocols such as RTSP and ONVIF, equipped with professional application software and universal SDK development package.
It is ideal choices for fields such as electronic circuits, education and research, and industrial automation.
Supporting multiple protocols such as RTSP and ONVIF, equipped with professional application software and universal SDK development package.
It is ideal choices for fields such as electronic circuits, education and research, and industrial automation.
Feature
High-quality image output
AT31 can accurately transmit on-site temperature data. Its electric focusing lens design enables the observations of multiple depth-of-field targets using the same lens, thus providing more accurate temperature measurements.
The device can output high-quality infrared images with a resolution of 384×288, supporting rapid temperature data analysis and determination.
The device can output high-quality infrared images with a resolution of 384×288, supporting rapid temperature data analysis and determination.
High-speed Frame Rate and Real-time Data Transmission
With an image and temperature frame rate of up to 50Hz, AT31 can capture temperature changes at a very high speed. It is very suitable for applications requiring real-time monitoring of temperature changes.
Equipped with a Gigabit network interface, the device also supports real-time transmission of on-site status temperature data, allowing for image monitoring and temperature data analysis at anytime.
Equipped with a Gigabit network interface, the device also supports real-time transmission of on-site status temperature data, allowing for image monitoring and temperature data analysis at anytime.
Wide Measurement Range and Temperature Compensation Algorithm
With a wide measurement range from -20°C to +550°C, AT31 is suitable for industrial scenarios with various high-temperature requirements. The device utilizes a temperature compensation algorithm to adjust for environmental factors and ensure measurement accuracy and reliability
Specification
| Thermal Module | |
| Detector Type | VOx, uncooled FPA detectors |
| Spectral Range | 8~14μm |
| NETD | ≤40mK(@25°C, F#1.0, 25 Hz) |
| Resolution | 640×512 |
| Pixel Pitch | 12μm |
| Focal Length | 13mm/25mm |
| Optical Module | |
| Sensor | 4MP 1/1.8″ Progressive Scan CMOS |
| Resolution | 2688×1520 |
| Focal Length | 6.5~130mm, 20x |
| Image Function | |
| Picture in Picture | Support |
| PTZ | |
| Pan | 360° continuous，0.1°~100°/s |
| Tilt | -90°~+90°，0.1°~60°/s |
| Preset | 256 |
| Scan mode | Preset/Pattern Scan/Patrol Scan/ Linear Scan/Panorama Scan |
| Wiper | wiper |
| Temperature Measurement | |
| Temperature Range | -20℃~+550℃ |
| Temperature Accuracy | ±2℃ or ±2% |
| Temperature Measurement | Support 4 temperature measure ment rules(fullframe, point, line, area) |
| Smart Function | |
| Fire Detection | Support |
| VCA | Support Line Crossing&Intrusion detection |
| 2-Way Audio | Support |
| Linkage Action | Video/ Snapshot/Email/Alarm output/sound and light alarm |
| System Interface | |
| Power | DC 12V±25% |
| Network | 1 RJ45 10M / 100M self-adaptive Ethernet port |
| Audio | 1 in/1 out |
| Alarm | 2 in/2 out |
| Storage | Micro SD memory（maximum 256G） |
| Reset | Support |
| Serial Port | 1 channel RS485, can support Pelco protocol |
| General | |
| Work Environment | -40℃~+70℃；<90%RH |
| Protection | IP66 |
| Power Consumption | max. 30w |
| Dimenstion(mm) | 358×166×203 |
| Weight | ≤5kg |
Application Scenariosa
Power Monitoring
Industrial Manufacturing
Machine Vision
Education and Research
