MFC460T Thermal Bullet Camera

China Moneypro
MFC4T thermal bullet camera equipped a high-resolution, 12 μm pixel pitch thermal detector with various lens options.
It supports tripwire/intrusion detection and it integrated temperature analysis methods and fire detection function.
It can be used for perimeter protection and fire prevention in residential areas and commercial facilities.
Support TPM technology and meeting the FIPS 140-3 Level 3 standard.

Feature

12μm Uncooled Infrared Detector

Adopting the latest 12μm uncooled infrared detectors, integrated with advanced infrared imaging algorithms for better image quality.

Intelligent Video Analysis

Support tripwire/intrusion detection, as well as intelligent detection of fire point.

Accurate Temperature Measuremen

Measurement range from -20°C to 550°C, accuracy ±2°C or 2%.

Platform Integration

Support ONVIF, provide SDK&demo for development; provide NVR and VMS software for application.

Specification

Thermal Module
Detector TypeVOx, uncooled FPA detectors
Spectral Range8~14μm
NETD≤40mK(@25°C, F#1.0, 25 Hz)
Resolution640×512
Pixel Pitch12μm
Focal Length9.1mm/13mm/19mm/25mm
Temperature Measurement
Temperature Range-20℃~+550℃
Temperature Accuracy±2℃ or ±2%
Temperature MeasurementSupport 4 temperature measure ment rules(fullframe, point, line, area)
Smart Function
Fire DetectionSupport
VCASupport Line Crossing & Intrusion detection
2-Way AudioSupport
Linkage ActionVideo/ Snapshot/Email/Alarm output/sound and light alarm
System Interface
PowerDC 12V±25%/POE(802.3at)
Network1 RJ45 10M / 100M self-adaptive Ethernet port
Audio1 in/1 out
Alarm2 in/1 out
StorageMicro SD memory（maximum 256G）
ResetSupport
Serial Port1 channel RS485, can support Pelco protocol
General
Work Environment-40℃~+70℃；<95%RH
ProtectionIP66
CertificationCE,ROHS,CE-EMC Test Report, FIPS 140-3 Level 3
Power Consumption≤4W
Dimenstion(mm)319.5×121.5×103.6
Weight≤1.5kg

Application Scenariosa
