MSP026B Two-Axis Servo Stabilization Platform
The MSP026B two-axis servo-stabilized platform consists of a dual-frame structure for pitch and azimuth, a high-precision gyroscope, servo control circuitry, and an image tracker. It features lightweight construction, high stability and precision, and high integration. It can be applied to unmanned vehicles, armored vehicles, unmanned boats, and sentry towers, working with payloads to perform day and night reconnaissance, surveillance, and target location tasks.
The servo stabilization platform, in conjunction with the optoelectronic payload, can achieve all-weather detection, identification, and tracking of ground targets, and output video in real time for mission personnel to view.
Servo stabilization platforms are mainly used in conjunction with optoelectronic payloads in scenarios such as air detection, ground detection, border and coastal defense, high-point monitoring, and border outposts.
I. Photos of the actual product
Figure 1 Product Image
II. Product Functions
a) It has two degrees of freedom: azimuth and pitch;
b) Possesses target tracking capabilities;
c) It has the function of calculating and transmitting azimuth and elevation angle data;
d) It has a communication interface that can be used for gimbal attitude control;
e) It has BeiDou positioning and orientation functions, with the BeiDou decoding board installed inside the gimbal and the dual BeiDou antennas externally mounted;
f) It has the ability to recognize external control handle button signals, and the handle is used to control the gimbal rotation and enter /exit the tracking function;
g) The electric pan-tilt head has button functions, which can control the horizontal and pitch rotation of the electric pan-tilt head through the buttons on the electric pan-tilt head itself. It has a one-key lock /unlock function and can display lock/unlock characters.
III. Platform
Unmanned boats, unmanned vehicles, and other moving and static base mounting platforms.
IV. Main Technical Parameters
| model | SP026B |
| Servo Platform | |
| Orientation angle | 360°×n (360° continuous rotation) |
| Pitch angle | -20° to +20° (0° is horizontal, negative is downward, and positive is upward) |
| Frame corner accuracy | ≤0.05° (1σ) |
| Stable accuracy | ≤0.05mrad (1σ) |
| Maximum turning speed | Azimuth ≥ 60°/s, Pitch ≥ 60°/s |
| Maximum turning acceleration | Azimuth ≥ 100°/s², Pitch ≥ 100°/s² |
| System Indicators | |
| Power supply voltage | 20V～32VDC |
| power | Stable power consumption: ≤25W (without load) |
| Load weight | ≥7Kg |
| weight | ≤7Kg |
| volume | ≤357mm×278mm×152mm |
| interface | |
| Communication interface | RS422 |
| Image Interface | HD-SDI/100Mbps Ethernet |
| Installation interface | See details: Mechanical Interface |
| Environmental adaptability | |
| Operating temperature | -40℃～＋60℃ |
| Storage temperature | -40℃～＋60℃ |
| Vibration conditions | The acceleration is 2g; 30 minutes each in the vertical, horizontal and longitudinal directions. |
| Impact conditions | Peak acceleration 20g, duration 11ms |
| Protection level | Protects against light rain and sandstorms |
V. Mechanical Dimensions and Installation Interfaces
Figure 2 Product Dimensions
