Photon MH615 Medium-Wave HOT Cooled Infrared Module
China Moneypro
The Photon MH615 medium-wave HOT cooled infrared module is provided with the high-performance T2SL cooled infrared FPA detector, is designed with SWaP, and is carried with the self-developed image processing algorithm.
It works flexibly and reliably and plots quickly. It supports multiple digital video interfaces, is suitable for multiple focus and continuous zoom lenses, and is widely applied in the mini pod, handheld, and other scenarios.
It provides an SDK, which is simple and easy to use, reducing secondary development costs.
It works flexibly and reliably and plots quickly. It supports multiple digital video interfaces, is suitable for multiple focus and continuous zoom lenses, and is widely applied in the mini pod, handheld, and other scenarios.
It provides an SDK, which is simple and easy to use, reducing secondary development costs.
Feature
1、Industry-Leading SWaP Design
The dimensions are as small as 76.5×69.2×46.6mm, weight is as low as 359g, and power consumption is as low as 6W, meeting the needs of miniaturized applications.
2、Delicate Images with High Sensitivity
The NETD is as low as 20mK, meeting the requirements of long-distance observation of tiny targets.
3、Self-Developed Algorithm for Intelligent Imaging
Equipped with a new self-developed image algorithm, it supports a wide dynamic range and adaptive integral time, providing the best imaging effect for different scenarios.
4、Fast Imaging for Timely Capture
Featuring the new generation T2SL detector, it has a resolution of up to 640×512, a frame rate of up to 50Hz, and a cooling time as low as 2.5 minutes, meeting the requirements of large-range dynamic target capture.
5、High Reliability and Durability
The mean time to failure (MTTF) is up to 20000h, and the operating temperature ranges from -40°C~ +70°C, ensuring reliable performance in extreme environments such as polar regions or deserts.
Specification
| Performance Indicators | |
| Detector Type | T2SL Cooled Infrared FPA |
| Resolution | 640×512 |
| Detector Frame Rate | 50 Hz/30 Hz |
| Pixel Pitch | 15μm |
| Spectral Band | 3.7～4.8μm |
| NETD | ≤20mK@F4.0，25℃/≤25mK@F5.5，25℃ |
| Image Adjustment | |
| Brightness/Contrast Adjustment | Manual/Auto |
| Polarity | Black-hot/White-hot (white-hot by default) |
| Palette | Multiple types support |
| Reticle | Display/Blank/Move |
| Image Processing | Non-uniformity correction, digital filter noise reduction, digital detail enhancement |
| Mirroring | Horizontal/Vertical/Diagonal |
| Power Supply | |
| Power Supply Range (typical) | 12±0.5V DC |
| Typical Power Consumption at 25°C Without Extension | Stable power consumption ≤ 6W, peak power consumption ≤ 12W@Cameralink/Stable power consumption ≤ 7W, peak power consumption ≤ 13W@SDl |
| Interface | |
| Analog Video | PAL |
| Digital Video | Cameralink/SDI |
| Serial Communication Interface | RS422 (default baud rate:115200) |
| Synchronization Mode | Internal synchronization (default)/External synchronization/Adaptive synchronization mode |
| Physical Characteristics | |
| Dimensions (Without lens) | 76.5×69.2×46.6mm |
| Weight (Without lens) | 364g@Cameralink/359g@SDI |
| Environment Adaptability | |
| Operating Temperature | -40°C~ +70°C |
| Storage Temperature | -45°C~ +75°C |
| Random Vibration | 4.16g |
| Shock | Final peak sawtooth wave, 40g, 11ms (18 times in three axes and six directions in total) |
Application Scenariosa
Perimeter Monitoring
Nature Reserve
Handheld Device
UAV
