Turing ML256 Uncooled Infrared Module (Imaging)
China Moneypro
Turing ML256 uncooled infrared module is equipped with an advanced 256×192 wafer detector with a dimension of 18×18mm. Thanks to its integrated design, it redefines standards in weight, dimension and power consumption (SWaP³) in the OEM module industry, providing excellent miniaturized solutions for consumer products.
Feature
Compatibility Design
- Its resolution is 256×192 and dimension is 18mm×18mm, which are consistent with those of the L384 mechanical interface for compatibility design.
Excellent Performance
- 50Hz imaging to provide a smooth image experience.
Multiple Selections
- The FOV is 20°~90° and the extension supports multiple interfaces such as DVP/USB/Analog video.
Specification
| Performance Indicators | |
| Detector Type | Uncooled VOx infrared detector |
| Resolution | 256×192 |
| Frame Rate | 50 Hz |
| Pixel Pitch | 12μm |
| Spectral Band | 8~14μm |
| NETD | ≤50mK@25°C |
| Image Adjustment | |
| Brightness/Contrast Adjustment | Manual/Auto |
| Polarity | Black-hot/White-hot |
| Palette | It supports multiple types |
| Reticle | Display/Blank/Move |
| Image Processing | Digital filtering noise reduction/Digital detail enhancement |
| Mirroring | Horizontal/Vertical/Diagonal |
| Power Supply | |
| Power Supply Range (typical) | 3.8~5.2V DC/1.8V/3.3V |
| Typical Power Consumption at 25°C Without Extension | ≤0.35W |
| Interface | |
| Digital Video | LVCMOS/BT.1120 |
| Serial Communication Interface | UART |
| Extension Components | USB 2.0 / Analog video |
| Physical Characteristics | |
| Dimensions (Without lens and extension components) | 18×18mm |
| Weight (3.2mm, without extension components) | About 8.7g |
| Lens Model | 2mm, 3.2mm, 7mm, 10mm, and 13mm |
| Environment Adaptability | |
| Operating Temperature | -20℃～60℃ |
| Storage Temperature | -45℃～+85℃ |
| Humidity | 5 ~ 95%, non-condensing |
| Product Certification | RoHS2.0 |
Application Scenariosa
UAV
Security Monitoring
Head-mounted Night Vision
Machine Vision
